Simpson Anchors  |  SKU: BPS 3/4-6  |  Barcode: 707392421306

Simpson BPS 3/4-6 Slotted Bearing Plate with 3/4" Bolt Diameter

$5.04

Description

Simpson Strong-Tie BPS 3/4-6 Description

The Simpson Strong-Tie BPS 3/4-6 Slotted Bearing Plate is designed for wood-to-concrete applications, offering adjustability and high load support.

Simpson Strong-Tie BPS 3/4-6 Includes

  • (1) Slotted Bearing Plate

Simpson Strong-Tie BPS 3/4-6 Features

  • Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
  • Slotted hole allows for adjustability
  • Available with a hot-dip galvanized finish for higher corrosion resistance
  • Heavy-duty construction from 3 Gauge steel
  • Compact size of 4.5" x 3"

Simpson Strong-Tie BPS 3/4-6 Applications

  • Wood-to-concrete fastening
  • Structural reinforcement in construction projects
  • Heavy-duty framing and load-bearing applications

Simpson Strong-Tie BPS 3/4-6 Installation Overview

  1. Position the edge of the plate washer within 1/2" of the sheathed edge of the sill plate for shearwall applications.
  2. Tighten the plate to each anchor bolt with a nut and standard cut-washer.
  3. Ensure proper alignment and secure fastening.

Simpson Strong-Tie BPS 3/4-6 Specifications

Material 3 Gauge Steel
Finish Plain or Hot-Dip Galvanized
Bolt Diameter 3/4"
Dimensions 4.5" x 3"
Weight 0.9 lb

NOTE: Standard cut-washer required with BPS slotted bearing plates. Washer not required when used with Titen HD heavy-duty screw anchors.
