3M 7000029006 Description
3M Lead Foil Tape 420 is an electrically and thermally conductive tape. This highly conformable tape resists flame, moisture, weather, UV degradation, chemicals and radiation. Mated with an easy release film liner, this malleable tape can be shaped into complex or detailed patterns or die cut into specific shapes to meet assembly and manufacturing process needs.
3M 7000029006 Includes
- (12) 3M Lead Foil Tape 420 Rolls
3M 7000029006 Features
- Electrically and thermally conductive lead foil tape
- Highly conformable and malleable to fit complex shapes and patterns
- Rubber based adhesive bonds to a variety of surfaces including most metals
- Resists flame, moisture, weather, UV degradation, chemicals, and radiation
- Performs over a wide temperature range from -60 Degree Fahrenheit to 225 Degree Fahrenheit
- Easy release film liner allows die cutting into specific shapes for assembly and manufacturing processes
- Suitable for masking applications in electroplating, radiation barrier, moisture barrier, and chemical milling
3M 7000029006 Specifications
| Product Type | Lead Foil Tape |
| Adhesive Type | Rubber |
| Backing Material | Lead Foil |
| Color | Silver |
| Width | 0.8 in |
| Length | 36 yd |
| Total Tape Thickness Without Liner | 6.8 mil |
| Backing Thickness | 4.7 mil |
| Adhesive Thickness | 2.1 mil |
| Minimum Operating Temperature | -60 Degree Fahrenheit |
| Maximum Operating Temperature | 225 Degree Fahrenheit |
| Tensile Strength | 20 lb/in |
| Shelf Life | 18 Month |
| Specifications Met | ASTM D3652, ASTM D3759, ASTM D3833 |
| Case Quantity | 12 Rolls per Case |
Toolup Part # :
854904
WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. www.p65warnings.ca.gov
