3M 7000133383 Description
3M Scotchlok MNHU10-250DMIX heat shrink male disconnect terminals provide a quick disconnect connection with moisture seal protection using adhesive lined polyolefin tubing. Built with electrolytic copper and corrosion resistant tin plating, they are designed for 12 to 10 AWG conductors and mate with a 0.25 in wide female tab.
3M 7000133383 Includes
- (125) 3M Scotchlok MNHU10-250DMIX Heat Shrink Male Disconnect Terminals
3M 7000133383 Features
- Male disconnect terminal for quick and easy disconnect
- Adhesive lined polyolefin heat shrink tubing helps seal against water and salt
- Mates with 0.25 in wide female tab
- Electrolytic copper construction for good conductivity
- Tin plated finish resists corrosion
- Withstands up to 221 Degree F (105 Degree C)
- Rated 600V for building wire and 1000V for signs fixtures or luminaires
- UL Listed CSA Certified and RoHS 2011/65/EU compliant
3M 7000133383 Specifications
| Part Number | MNHU10-250DMIX |
| Disconnect Type | Male |
| Terminal Style | Fully Insulated |
| Insulation Material | Heat Shrink |
| Color | Yellow |
| Wire Range | 12 to 10 AWG |
| Connection Width | 0.25 in |
| Maximum Recommended Voltage Rating | 600 V |
| Maximum Operating Temperature | 105 Degree Celsius |
