Condux 08642437 1.00" - 1.24" Cable Dia. Blue Non-Conductive Pulling Grip
Free Shipping
$351.08
$468.09
Unit price
/
Unavailable
Description
Description
Condux 08642437 Description
Non-Conductive Pulling Grips are made of a high strength, non-conductive aramid fiber and are available for pulling single cable or cable bundles. Their braided double weave design adds strength and positive holding power. They were developed for use by utilities for pulling overhead distribution lines in close proximity to energized lines and hardware.
Condux 08642437 Includes
- (1) 1.00" - 1.24" Cable Dia. Blue Non-Conductive Pulling Grip
Condux 08642437 Specifications
| Part Number | 08642437 |
| Description | 036-28-004 |
| Color | Blue |
| Cable Diameter Range | 1.00–1.24 in. (25–31 mm) |
| Approximate Breaking Strength | 6,000 lbs (26,688 N) |
| Eye Length (E) | 6.5 in. (165 mm) |
| Mesh length at nominal diameter (M) | 36.0 in. (914 mm) |
| Cable Diameter (A) | .63 in. (16 mm) |
