Condux 08642443 1.25" - 1.49" Cable Dia. White Non-Conductive Pulling Grip
Free Shipping
$324.17
$432.24
Unit price
/
Unavailable
Description
Description
Condux 08642443 Description
Non-Conductive Pulling Grips are made of a high strength, non-conductive aramid fiber and are available for pulling single cable or cable bundles. Their braided double weave design adds strength and positive holding power. They were developed for use by utilities for pulling overhead distribution lines in close proximity to energized lines and hardware.
Condux 08642443 Includes
- (1) 1.25" - 1.49" Cable Dia. White Non-Conductive Pulling Grip
Condux 08642443 Specifications
| Part Number | 08642443 |
| Description | 036-28-005 |
| Color | White |
| Cable Diameter Range | 1.25 – 1.49 in. (32 – 38 mm) |
| Approximate Breaking Strength | 6,000 lbs (26,688 N) |
| Eye Length (E) | 6.7 in. (170 mm) |
| Mesh length at nominal diameter (M) | 41.5 in. (1,054 mm) |
| Cable Diameter (A) | .63 in. (16 mm) |
