Condux 08917550 350 kcmil White Clevis Head Reusable Power Pulling Eye
Free Shipping
$303.99
Unit price
/
Unavailable
Description
Description
Condux 08917550 Description
The Clevis Head Power Pulling Eyes feature a slotted head with clevis pin to allow direct attachment to the Condux multiple pulling harness. When pulling multiple cables into a single conduit, the conductors can be attached to a harness and installation is simplified to a single pull of one assembly. Each Clevis Head Power Pulling Eye includes a clevis socket, sleeve nut, and plug.
Condux 08917550 Includes
- (1) Clevis Socket
- (1) Sleeve Nut
- (1) Plug
Condux 08917550 Features
- Slotted Head with Clevis Pin
- Will fit all Condux Pulling Harnesses
Condux 08917550 Specifications
| Part Number | 08917550 |
| Cable Size | 350 kcmil |
| Color | White |
| Maximum Conductor Diameter | .681 in. (17 mm) |
| Max Eye OD (A) | 1.25 in. (32 mm) |
| Slot Width (B) | .56 in. (14 mm) |
| Slot Depth (C) | 1.34 in. (34 mm) |
| Pin Diameter (D) | .38 in. (10 mm) |
| Pin Center (E) | .59 in. (15 mm) |
| Replacement Plug Part Number | 08917523 |
| Load Rating | 2500 lbs (1134 kg) |
