Condux | SKU:
08918440
Condux 08918440 Reusable Power Pulling Eye, Standard Head 5000 kcmil White
Free Shipping
$867.14
$921.34
Unit price
/
Unavailable
Description
Description
Condux 08918440 Description
The Standard Head Power Pulling Eyes are an excellent alternative when pulling multiple cables into a single conduit. Single conductors can be attached to a Condux Multiple Pulling Harness with links or with Condux swivels. Installation is then simplified to a single pull of one assembly. Each Standard Power Pulling Eye includes an eye socket, sleeve nut, and plug.
Condux 08918440 Includes
- (1) Reusable Power Pulling Eye, Standard Head 5000 kcmil White
Condux 08918440 Specifications
| Cable Size | 5000 kcmil |
| Color | White |
| Max Conductor Diameter | 2.500" |
| Max Eye OD | 4.500" |
| Hole Diameter | 1.31" |
| Eye Thickness | 1.50" |
| Replacement Plug | 08918423 |
| Working Load | 59,000 lbs |
