Condux 08918555 1000 kcmil Orange Standard Head Reusable Power Pulling Eye
Free Shipping
$519.45
Unit price
/
Unavailable
Description
Description
Condux 08918555 Description
The Standard Head Power Pulling Eyes are an excellent alternative when pulling multiple cables into a single conduit. Single conductors can be attached to a Condux Multiple Pulling Harness with links or with Condux swivels. Installation is then simplified to a single pull of one assembly. Each Standard Power Pulling Eye includes an eye socket, sleeve nut, and plug.
Condux 08918555 Includes
- (1) Eye Socket
- (1) Sleeve Nut
- (1) Plug
Condux 08918555 Specifications
| Part Number | 08918555 |
| Cable Size | 1000 kcmil |
| Color | Orange |
| Maximum Conductor Diameter | 1.203 in. (31 mm) |
| Max Eye OD | 2.000 in. (51 mm) |
| Hole Diameter (D) | 1.00 in. (25 mm) |
| Eye Thickness (T) | .50 in. (13 mm) |
| Replacement Plug Part Number | 08917123 |
| Working Load | 13,500 lbs (60.0 kn) |
