Eastman 20YE545072B Description
The Eastman 72 in. gas connector features a 1/2 in. OD stainless steel flexible tube with a yellow epoxy coating for added protection against corrosion, stains, and UV exposure. Designed for water heaters, dryers, and other moderate-use gas appliances, it is suitable for natural gas and LP applications and includes 3/4 in. MIP and 1/2 in. MIP fittings for installation.
Eastman 20YE545072B Includes
- (1) 72 in. 1/2 in. OD Gas Connector
- (1) 3/4 in. MIP Tapped 1/2 in. FIP Fitting
- (1) 1/2 in. MIP Tapped 3/8 in. FIP Fitting
Eastman 20YE545072B Features
- 72 in. flexible 1/2 in. OD stainless steel gas connector
- Yellow epoxy coating helps resist corrosion, chemical stains, and UV exposure
- Suitable for water heaters, dryers, and other moderate-use gas appliances up to 49,100 BTU
- Compatible with natural gas and LP applications
- Approved for indoor and outdoor use
- Deep corrugations enhance flexibility for easier installation
- Factory leak tested for dependable performance
- Certified to applicable ANSI and CSA standards
- Backed by a 5-year limited warranty
Eastman 20YE545072B Specifications
| Product Type | Gas connector |
| Length | 72 in. |
| Outside Diameter | 1/2 in. |
| Material | Stainless steel |
| Coating | Yellow epoxy-coated |
| Connection Type | MIP x MIP |
| Connection Size | 3/4 in. x 1/2 in. |
| Compatible Fuel Type | Natural gas and LP |
| BTU Rating | 49,100 BTU |
| Maximum Pressure | 0.5 PSI |
| Working Temperature Range | -20 Degree F to 150 Degree F |
| Indoor Outdoor Use | Indoor and outdoor |
| Corrosion Resistant | Yes |
| Flexible | Yes |
| Fitting Material | Zinc |
| Excess Flow Valve | No |
| Package Quantity | 1 |
| Warranty | 5-year limited |
Toolup Part # :
882902
