Greenlee | SKU:
EK12IDLX12
Greenlee EK12IDLX12 12 Ton Crimper Indent, Li-Ion, Standard, 12V
Free Shipping
$5,148.05
$6,513.60
Unit price
/
Unavailable
Loading delivery estimate...
Description
Description
Greenlee EK12IDLX12 Description
The Greenlee EK12IDLX are hand-held, self-contained, dieless crimping tools intended to crimp aluminum and copper connectors onto electrical cable. These tools have a retraction stop feature which allows the operator to stop the retraction motion of the ram to shorten cycle time. The EK12IDLX also features Bluetooth connectivity, which is enabled through the Gator Eye App.
Greenlee EK12IDLX12 Includes
- (1) Crimping tool
- (2) Batteries
- (1) Charger
- (1) Case
Greenlee EK12IDLX12 Features
- Equipped with Bluetooth™ Communication enabled via the Greenlee Gator Eye app
- Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback
- Intelligent Crimping System Technology includes a pressure sensor that monitors the crimping force of each crimp and provides the operator a visual and audible alert if the force is below specifications
- State of the art 18V lithium ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times
- Automatic Retraction Stop (ARS) which retracts the ram just enough to get ready for the next cycle saving time and energy
- LED light provides the operator with the battery charge and tool maintenance status
- Two-stage hydraulic system provides fast advance and power speeds, saving time
- Forward handle position improves tool balance
- One trigger controls all tool functions
- Crimping head rotates 350°
- Tools automatically retract when the crimping cycle is complete
- Overmolded tacky grip areas make gripping the tool easier and more comfortable
- LED work light illuminates dark work areas
- Greenlee battery-powered crimping tools now use bio-degradable oil
- Smart chargers control the charging current, charging voltage and battery temperature to maximize battery life
- Flip open crimping head will allow crimping of 4 AWG-1000 kcmil copper or 6 AWG-1000 kcmil aluminum with no dies to change
- Available with 120V, 12V or 230V battery charger or with 120V or 230V corded adapter in place of batteries and charger
Greenlee EK12IDLX12 Specifications
| Crimping Force | 24000 lbs (106 kN) |
| Crimping Capacity | 1000 Kcmil (MCM) Cu & Al |
| Wire Size | 4 AWG - 1000 kcmil Cu, 6 AWG - 1000 kcmil Al |
| Type | Dieless Style Crimper |
| Connector Type | Color-Coded Lugs and Splices |
| Handle Type | Pistol Style with Over Molded Rubber Grip |
| Application | 12 Ton Crimping |
| Standard | C/US UL Listed |
| Overall Length | 16.5" (420mm) |
