HoldRite HR100412-4-555 Description
The HoldRite strut-mounted cushion clamp is designed to support 4-1/8 in. OD tube while eliminating metal-to-metal contact between the piping, clamp, and strut. Made from 304 stainless steel for corrosion resistance, it helps withstand harsh environments, supports fast installation, and includes a nylon insert locknut.
HoldRite HR100412-4-555 Includes
- (1) Strut-Mounted Cushion Clamp
- (1) Nylon Insert Locknut
HoldRite HR100412-4-555 Features
- Designed for 4-1/8 in. OD tube
- 304 stainless steel construction for corrosion resistance
- Eliminates metal-to-metal contact between piping, clamp, and strut
- Resists fuels, oils, gases, greases, solvents, mineral acids, and other harsh materials
- Allows piping to be added or removed without disturbing adjacent lines
- Permits various line sizes to be mixed to suit the installation
- Center distances between conductors may be varied
- Provides fast and simple installation
- Compatible with copper, PEX, and other materials
- Working temperature range from -65 to 275 DegreeF
HoldRite HR100412-4-555 Specifications
| Product Type | Strut-Mounted Cushion Clamp |
| Material | 304 Stainless Steel |
| Tube Outer Diameter | 4-1/8 in. |
| Mount Type | Strut Mounted |
| Operating Temperature Min | -65 DegreeF |
| Operating Temperature Max | 275 DegreeF |
| Compatible Materials | Copper, PEX, and other materials |
| Included Hardware | Nylon Insert Locknut |
| Case Quantity | 5 |
| Each Length | 7 in. |
| Each Width | 5.5 in. |
| Each Height | 1.75 in. |
| Each Shipping Weight | 0.86 lb |
