ITW Buildex 1575553 Description
The ITW Buildex 1575553 is a 12-14 x 1 in Teks 3 self-drilling screw designed for attaching low profile architectural metal roof clips to steel purlins or wood supports. Its pancake head helps provide proper panel installation, while the sharp drill point and Climacoat finish support efficient drilling performance and corrosion resistance.
ITW Buildex 1575553 Includes
- (250) 12-14 x 1 in Teks 3 Pancake Head Self-Drilling Screws
ITW Buildex 1575553 Features
- Designed for attaching low profile architectural metal roof clips to steel purlins or wood supports
- Pancake head style helps ensure proper installation of metal roof panels
- Sharp convex drill point with precise cutting edges improves drill performance with less effort
- Point-to-thread design helps maximize pullout performance and minimize backout
- Climacoat finish provides corrosion resistance and lower tapping torque
- Phillips drive design supports stable driver engagement during installation
ITW Buildex 1575553 Specifications
| Product Type | Self-Drilling Screw |
| Diameter | #12 |
| Threads Per Inch | 14 |
| Length | 1 in. |
| Material | Steel |
| Steel Grade | C1022 |
| Finish | Climacoat |
| Drive Type | Phillips |
| Head Type | Pancake |
| Point Size | #3 |
| Installation Tool | #2 PSD Bit |
| Tensile Strength | 1,983 lbf |
| Torque | 78 lbs |
| Drill - Tap Capacity | .036-.210 |
| Max Material Attachments | 0.550 |
| Max Material Range | .036-.550 |
| Application | Metal roof clips to steel purlin or wood supports |
| Quantity | 250 per bag |
