Kenwood NX-P1200ISNVK 5 Watt, Quad-Zone, 16 Channel, Digital NXDN/Analog, VHF Two-Way Radio
Description
Description
Kenwood NX-P1200ISNVK Description
The Kenwood ProTalk NX-P1200ISNVK is a 5 Watt 16 Channel/4 zones (total 64 channels) Intrinsically Safe Digital VHF Two Way Radio that can operate on either DMR or NXDN Digital Standards based on your specific need. The NX-P1200ISNV is approved for Class I, Div. 1, Group D and is also approved for non-Incendive use in Class I, Div. 2, Groups A, B, C, D hazardous locations. You’ll find this is an affordable digital radio with 16 easily accessible channels on the dial with added functionality for those needing more channels. Kenwood NX-P1200ISNV radios are impressively built, exceeding Military Standard for Durability and Water Resistance while providing Kenwood’s impressive audio quality.
Kenwood NX-P1200ISNVK Includes
- (1) VHF Two Way Radio
- (1) Heavy Duty Lithium Ion Battery
- (1) Belt Clip
- (1) Removable Antenna
- (1) Fast Charger
Kenwood NX-P1200ISNVK Features
- Multi-protocol digital radio: Designed to operate under NXDN or DMR digital and FM analog protocols
- Battery Level Indication
- Multi-status function indication
- RF output power 5W both on VHF/UHF
- Mixed Zone – analog and digital
- Renowned KENWOOD Audio Quality: TX/RX audio profile with optimizable digital processor
- Audio Equalizer: Flat, High, Low
- Auto Gain Control: On, High, Low, Off
- Noise Suppressor
- Microphone type settings
- Multiple Scan Functions; Dual Priority, Single Priority, Single Zone, Multi, Normal Scan
- VOX & PTT –triggered Semi- VOX, Voice-operated TX
- Emergency Function: Customizable Emergency Profile
- Lone Worker
- Max / Min Volume setting & Volume control
- Voice Announcement
- Remote Stun / Kill / Check
- Front Panel Programming Mode (for Keypad model)
- Electronic Serial Number (ESN)
- MIL-STD-810 C/D/E/F/G
- IP54 and IP55
- Intrinsically Safe Option
Kenwood NX-P1200ISNVK Specifications
| Depth | 1.48" |
| Width | 2.13" |
| Height | 4.84" |
| Pre-set Frequencies | 151-159 MHz |
| Max. Channels per Radio | 64 |
| Number of Zones | 4 |
| Channel Spacing Analog - Digital | 25*1 / 12.5 kHz, 12.5 / 6.25 kHz |
| Power Supply | 7.5 VDC ±20 % |
| Battery Life (5-5-90) | KNB-45L (2000mAh) |
| Operating Temperature(Radio only)*2 | -22°F to +140°F (-30°C to +60°C) |
| Frequency Stability (-30 to +60°C; +25°C Ref.) | ±0.5 ppm |
| Antenna Impedance | 50 ohm |
| NXDN® @ 6.25 kHz Digital (3% BER) | 0.18 microvolt |
| NXDN® @ 12.5 kHz Digital (3% BER) | 0.22 microvolt |
| Analog @ 12.5/25 kHz (12 dB SINAD) | 0.20 microvolt / 0.24 microvolt |
| Selectivity Analog @ 12.5 / 25 kHz | 68 dB / 74 dB |
| Intermodulation Distortion | 70 dB |
| Spurious Rejection | 70 dB |
| Receiver Audio Distortion | 7% |
| Audio Output Power | 1 W / 12 ohm (Internal Output), 500 mW / 8 ohm (External Output) |
| RF Power Output*2 (High / Low) | 5 W / 4 W / 1 W |
| Spurious Emission | -70 dB |
| FM Hum & Noise Analog @ 12.5 / 25 kHz | 40 dB / 45 dB |
| Transmitter Audio Distortion | 2% |
