Makita XAG23ZU1 18V X2 LXT (36V) Brushless 9" Cut-Off/Angle Grinder w/ AWS
Description
Description
Makita XAG23ZU1 Description
Makita delivers corded grinding performance without the cord with the 18V X2 LXT® Lithium-Ion (36V) Brushless 9 In. paddle switch Cut-Off/Angle Grinder with electric brake and AWS™ (tool only, battery and charger sold separately). It's powered by a Makita Brushless Motor for longer run time, increased power and speed, and longer tool life. For the most demanding applications, Makita's exclusive Automatic Speed Change™ technology automatically adjusts speed and torque during operation for optimal performance. The XAG23ZU1 is ideal for grinding and cutting a wide range of materials including tile, concrete, pipe, conduit, and more. For improved efficiency, it’s equipped with auto-start wireless system (AWS™) technology. AWS™ utilizes Bluetooth® technology for wireless communication between the tool and dust extractor (sold separately). When the trigger is engaged, the AWS™-equipped dust extractor powers-up. When the trigger is released, the dust extractor powers-down. AWS™ is intelligent communication that eliminates cords and excessive noise since the dust extractor runs only when the tool is running. Additional features include the BL™ Brushless Motor, Active Feedback-sensing Technology (AFT®), and an electric brake that stops the grinding or cut-off wheel in 2 seconds or less. The BL™ Brushless Motor eliminates carbon brushes, enabling the motor to run cooler and more efficiently for longer life. AFT® turns the motor off if rotation speed suddenly slows or the wheel is forced to a stop.
Makita XAG23ZU1 Includes
- (1) 9" Tool-less Wheel Guard (123543-6)
- (1) 9" Cut-Off Wheel Guard (122913-6)
- (1) 9" x 1/4" x 7/8" INOX Grinding Wheel, 36 Grit (A-96051)
- (1) 9" x .075" x 7/8" INOX Thin Cut-Off Wheel, 60 Grit (B-12675)
- (1) Side Handle (143486-6)
- (1) Lock Nut Wrench (782412-6)
- (1) Auto-Start Wireless Transmitter (198901-5)
Makita XAG23ZU1 Features
- The BL™ Brushless Motor eliminates carbon brushes, enabling the BL™ Motor to run cooler and more efficiently for longer life; delivers 6,000 RPM
- Two 18V LXT® Lithium-Ion batteries deliver corded power without leaving the 18V LXT® battery platform (batteries not included)
- Active Feedback-sensing Technology (AFT®) turns the motor off if rotation of the wheel is suddenly forced to stop
- Electric brake stops the grinding or cut-off wheel in 4.5 seconds or less for maximum productivity
- Auto-start wireless system (AWS™) utilizes Bluetooth® technology for wireless power-on/off communication between tool and dust extractor
- Dust extraction cutting guard and AWS™ dust extractor are available for concrete cutting applications
- Automatic Speed Change™ technology adjusts speed and torque during operation for optimum performance
- Soft start suppresses start-up reaction for smooth start-ups and longer gear life
- Anti-restart protection engineered to prevent motor start up when battery is inserted with switch locked on
- Rear handle paddle switch with no lock-on feature
- Vibration absorbing back handle is isolated from the motor housing effectively reducing vibration to the operator's hands
- Rubberized soft grip handle provides increased comfort on the job
- The electronically-controlled BL™ Brushless Motor efficiently uses energy to match torque and RPM to the changing demands of the application
- L.E.D. battery charge indicator alerts user of drained power for each of the two batteries (batteries not included)
- Large spindle lock button for easier wheel changes while wearing gloves
- Wire mesh intake covers are engineered to prevent debris from entering motor
- Tool-less wheel guard for quick and easy adjustments
- Extreme protection technology (XPT™) is engineered for improved dust and water resistance for operation in harsh conditions
Makita XAG23ZU1 Specifications
| Wheel Diameter | 9" |
| Automatic-start Wireless System (AWS™) | Yes (Transmitter Included) |
| Battery | 2X 18V LXT® Lithium-Ion |
| No Load Speed | 6,000 RPM |
| Spindle Thread | 5/8" - 11 UNC |
| Max. Cutting Depth | 3" |
| Lock-On Switch | No |
| Lock-Off Switch | Yes |
| Switch Type | Rear trigger handle |
| Electrical Brake | Yes |
| Variable speed control dial | No |
| Overall Length | 19-5/8" |
| Net Weight (with battery) | 13.01 lbs. |
| Power Type | Cordless |
| Shipping Weight | 19.11 lbs. |
