Proto | SKU:
J07523T
Proto J07523T 3/4" DRIVE IMPACT SOCKET 1-7/16" - 12 POINT
$23.47
$44.66
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 3/4" DRIVE IMPACT SOCKET 1-7/16" - 12 POINT
FEATURES:
• Proto® 12 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 1-7/16''
• NUT END OUTSIDE DIAMETER: 2-1/4"
• DRIVE END OUTSIDE DIAMETER: 1-3/4"
• NUT DEPTH: 1-1/8"
• BOLT CLEARANCE DEPTH: 1-1/8"
• OVERALL LENGTH: 2-5/16"
• WEIGHT: 1.34 lbs
• CRUSH RETAINING RING: JRR07526
• O-RING: J07500R
• RETAINING PIN: J07500P
• DRIVE SIZE: 3/4"
• POINT SIZE: 12
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• (1) 3/4" DRIVE IMPACT SOCKET 1-7/16" - 12 POINT
FEATURES:
• Proto® 12 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 1-7/16''
• NUT END OUTSIDE DIAMETER: 2-1/4"
• DRIVE END OUTSIDE DIAMETER: 1-3/4"
• NUT DEPTH: 1-1/8"
• BOLT CLEARANCE DEPTH: 1-1/8"
• OVERALL LENGTH: 2-5/16"
• WEIGHT: 1.34 lbs
• CRUSH RETAINING RING: JRR07526
• O-RING: J07500R
• RETAINING PIN: J07500P
• DRIVE SIZE: 3/4"
• POINT SIZE: 12
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
