Proto J09938 #5 SPLINE DRIVE IMPACT SOCKET 2-3/8" - 6 POINT
$167.59
$334.20
Unit price
/
Unavailable
Description
Description
Proto J09938 Includes
- (1) #5 SPLINE DRIVE IMPACT SOCKET 2-3/8" - 6 POINT
Proto J09938 Features
- Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
- The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
Proto J09938 Specifications
| SIZE | 2-3/8" |
| NUT END OUTSIDE DIAMETER | 3-3/4" |
| DRIVE END OUTSIDE DIAMETER | 2-3/8" |
| NUT DEPTH | 1-11/16" |
| BOLT CLEARANCE DEPTH | 2-7/16" |
| OVERALL LENGTH | 3-57/64" |
| WEIGHT | 4.80 lbs |
| DRIVE SIZE | #5 Spline |
| POINT SIZE | 6 |
| FINISH | Black Oxide |
| LENGTH TYPE | Standard |
| UNIT OF MEASURE | Fractional |
