Proto | SKU:
J09948
Proto J09948 #5 SPLINE DRIVE IMPACT SOCKET 3" - 6 POINT
Free Shipping
$241.27
$481.18
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) #5 SPLINE DRIVE IMPACT SOCKET 3" - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 3"
• NUT END OUTSIDE DIAMETER: 4-1/4"
• DRIVE END OUTSIDE DIAMETER: 2-3/8"
• NUT DEPTH: 2"
• BOLT CLEARANCE DEPTH: 2-13/64"
• OVERALL LENGTH: 4-39/64"
• WEIGHT: 7.93 lbs
• DRIVE SIZE: #5 Spline
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• (1) #5 SPLINE DRIVE IMPACT SOCKET 3" - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 3"
• NUT END OUTSIDE DIAMETER: 4-1/4"
• DRIVE END OUTSIDE DIAMETER: 2-3/8"
• NUT DEPTH: 2"
• BOLT CLEARANCE DEPTH: 2-13/64"
• OVERALL LENGTH: 4-39/64"
• WEIGHT: 7.93 lbs
• DRIVE SIZE: #5 Spline
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
