Proto | SKU:
J10021S
Proto J10021S 1" DRIVE IMPACT SOCKET 1-5/16" - 8 POINT
$6.53 off
$46.98
$53.51
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 1" DRIVE IMPACT SOCKET 1-5/16" - 8 POINT
FEATURES:
• Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
• Tight tolerances for snug fit on fastener.
• Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
• Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
• Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
• Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
• Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.
SPECIFICATIONS:
• SIZE: 1-5/16"
• NUT END OUTSIDE DIAMETER: 2-1/2"
• DRIVE END OUTSIDE DIAMETER: 2-1/2"
• NUT DEPTH: 25/32"
• BOLT CLEARANCE DEPTH: 1-1/2"
• OVERALL LENGTH: 2-13/16"
• WEIGHT: 2.07 lbs
• CRUSH RETAINING RING: JRR10028
• O-RING: J10000R1
• RETAINING PIN: J10000P1
• DRIVE SIZE: 1"
• POINT SIZE: 8
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• (1) 1" DRIVE IMPACT SOCKET 1-5/16" - 8 POINT
FEATURES:
• Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
• Tight tolerances for snug fit on fastener.
• Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
• Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
• Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
• Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
• Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.
SPECIFICATIONS:
• SIZE: 1-5/16"
• NUT END OUTSIDE DIAMETER: 2-1/2"
• DRIVE END OUTSIDE DIAMETER: 2-1/2"
• NUT DEPTH: 25/32"
• BOLT CLEARANCE DEPTH: 1-1/2"
• OVERALL LENGTH: 2-13/16"
• WEIGHT: 2.07 lbs
• CRUSH RETAINING RING: JRR10028
• O-RING: J10000R1
• RETAINING PIN: J10000P1
• DRIVE SIZE: 1"
• POINT SIZE: 8
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
