Proto J10032S 1" DRIVE IMPACT SOCKET 2" - 8 POINT
$150.02
$285.58
Unit price
/
Unavailable
Description
Description
Proto J10032S Includes
- (1) 1" DRIVE IMPACT SOCKET 2" - 8 POINT
Proto J10032S Features
- Drive end chamfer and four detents help provide quick positive engagement with drive tool on any of the socket drive walls.
- Tight tolerances for snug fit on fastener.
- Large clearance holes, concentric opening and nut end chamfer make it easy to position socket on fasteners.
- Made from high-strength steel to help minimize wall thickness and provide access to fasteners in recesses and where nuts and bolts protrude.
- Impact sockets are used wherever powered drive tools are used to install or remove fasteners.
- Impact sockets are designed to withstand the high torque and force associated with impact tools in repetitive application.
- Features two through holes and a groove to accept a Proto® Retaining Ring or pin and O-ring to help secure the socket to the drive tool anvil.
Proto J10032S Specifications
| SIZE | 2'' |
| NUT END OUTSIDE DIAMETER | 3-1/2" |
| DRIVE END OUTSIDE DIAMETER | 3-1/2" |
| NUT DEPTH | 1'' |
| BOLT CLEARANCE DEPTH | 1-15/16" |
| OVERALL LENGTH | 3-1/2" |
| WEIGHT | 4.42 lbs |
| CRUSH RETAINING RING | JRR10034 |
| O-RING | J10000R2 |
| RETAINING PIN | J10000P2 |
| DRIVE SIZE | 1" |
| POINT SIZE | 8 |
| FINISH | Black Oxide |
| LENGTH TYPE | Standard |
| UNIT OF MEASURE | Fractional |
