Proto | SKU:
J10055M
Proto J10055M 1" DRIVE IMPACT SOCKET 55 MM - 6 POINT
$56.91
$108.34
Unit price
/
Unavailable
Description
Description
Proto J10055M Includes
- (1) 1" DRIVE IMPACT SOCKET 55 MM - 6 POINT
Proto J10055M Features
- Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
- The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
- The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
- The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
- Stamped size for easy reference.
- Side locking hole.
Proto J10055M Specifications
SIZE | 55 mm |
NUT END OUTSIDE DIAMETER | 3-1/4" |
DRIVE END OUTSIDE DIAMETER | 2-13/32" |
NUT DEPTH | 1-9/16'' |
BOLT CLEARANCE DEPTH | 1-9/16" |
OVERALL LENGTH | 3-1/8" |
WEIGHT | 3.71 lbs |
CRUSH RETAINING RING | JRR10040 |
DRIVE SIZE | 1" |
POINT SIZE | 6 |
FINISH | Black Oxide |
LENGTH TYPE | Standard |
UNIT OF MEASURE | Metric |
SPECIFICATION ASME | ASME B107.110-2012 |
