Proto  |  SKU: J10075M  |  Barcode: 662679977535

Proto J10075M 1" DRIVE IMPACT SOCKET 75 MM - 6 POINT

$137.87 $227.55

Description

Proto J10075M Includes

  • (1) 1" DRIVE IMPACT SOCKET 75 MM - 6 POINT

Proto J10075M Features

  • Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
  • Stamped size for easy reference.
  • Side locking hole.

Proto J10075M Specifications

SIZE 75 mm
NUT END OUTSIDE DIAMETER 4"
DRIVE END OUTSIDE DIAMETER 2-3/4"
NUT DEPTH 2-13/64''
BOLT CLEARANCE DEPTH 2-11/16"
OVERALL LENGTH 3-27/32"
WEIGHT 6.15 lbs
DRIVE SIZE 1"
POINT SIZE 6
FINISH Black Oxide
LENGTH TYPE Standard
UNIT OF MEASURE Metric
SPECIFICATION ASME ASME B107.110-2012
