Proto | SKU:
J15026L
Proto J15026L 1-1/2" DRIVE DEEP IMPACT SOCKET 1-5/8" - 6 POINT
$148.96
$270.08
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 1-1/2" DRIVE DEEP IMPACT SOCKET 1-5/8" - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 1-5/8"
• NUT END OUTSIDE DIAMETER: 2-7/8"
• DRIVE END OUTSIDE DIAMETER: 3-1/4"
• NUT DEPTH: 31/32"
• BOLT CLEARANCE DEPTH: 4-1/8"
• OVERALL LENGTH: 5-3/4"
• WEIGHT: 9.37 lbs
• CRUSH RETAINING RING: JRR15046
• DRIVE SIZE: 1-1/2"
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Deep
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
• (1) 1-1/2" DRIVE DEEP IMPACT SOCKET 1-5/8" - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 1-5/8"
• NUT END OUTSIDE DIAMETER: 2-7/8"
• DRIVE END OUTSIDE DIAMETER: 3-1/4"
• NUT DEPTH: 31/32"
• BOLT CLEARANCE DEPTH: 4-1/8"
• OVERALL LENGTH: 5-3/4"
• WEIGHT: 9.37 lbs
• CRUSH RETAINING RING: JRR15046
• DRIVE SIZE: 1-1/2"
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Deep
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
