Proto | SKU:
J15038M
Proto J15038M 1-1/2" DRIVE IMPACT SOCKET 38 MM - 6 POINT
$132.63
$240.47
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 1-1/2" DRIVE IMPACT SOCKET 38 MM - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 38 mm
• NUT END OUTSIDE DIAMETER: 2-7/8"
• DRIVE END OUTSIDE DIAMETER: 3-1/4"
• NUT DEPTH: 7/8"
• BOLT CLEARANCE DEPTH: 1-7/16"
• OVERALL LENGTH: 3-1/4"
• WEIGHT: 4.85 lbs
• CRUSH RETAINING RING: JRR10034
• O-RING: J10000R2
• RETAINING PIN: J10000P2
• DRIVE SIZE: 1-1/2"
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Metric
• (1) 1-1/2" DRIVE IMPACT SOCKET 38 MM - 6 POINT
FEATURES:
• Proto® 6 Point Impact Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
• Stamped size for easy reference.
• Side locking hole.
SPECIFICATIONS:
• SIZE: 38 mm
• NUT END OUTSIDE DIAMETER: 2-7/8"
• DRIVE END OUTSIDE DIAMETER: 3-1/4"
• NUT DEPTH: 7/8"
• BOLT CLEARANCE DEPTH: 1-7/16"
• OVERALL LENGTH: 3-1/4"
• WEIGHT: 4.85 lbs
• CRUSH RETAINING RING: JRR10034
• O-RING: J10000R2
• RETAINING PIN: J10000P2
• DRIVE SIZE: 1-1/2"
• POINT SIZE: 6
• FINISH: Black Oxide
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Metric
