Proto  |  SKU: J5207MH  |  Barcode: 662679161194

Proto J5207MH 3/8" Drive Socket 7 mm - 6 Point

$5.46 $10.17

Description

Proto J5207MH Includes

  • (1) 3/8" DRIVE SOCKET 7 MM - 6 POINT

Proto J5207MH Features

  • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Proto J5207MH Specifications

SIZE 7 mm
NUT END OUTSIDE DIAMETER 27/64"
DRIVE END OUTSIDE DIAMETER 43/64"
NUT DEPTH 1/4"
BOLT CLEARANCE DEPTH 39/64"
OVERALL LENGTH 1-3/32"
WEIGHT 0.05 lbs
DRIVE SIZE 3/8"
POINT SIZE 6
FINISH Full Polish
LENGTH TYPE Standard
UNIT OF MEASURE Metric
SPECIFICATION ASME ASME B107.110-2012
SPECIFICATION AS SAE AS4984A
