Proto  |  SKU: J5208MH  |  Barcode: 662679161231

Proto J5208MH 3/8" Drive Socket 8 mm - 6 Point

$6.36 $10.06

Description

Proto J5208MH Includes

  • (1) 3/8" DRIVE SOCKET 8 MM - 6 POINT

Proto J5208MH Features

  • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Proto J5208MH Specifications

SIZE 8 mm
NUT END OUTSIDE DIAMETER 15/32"
DRIVE END OUTSIDE DIAMETER 43/64"
NUT DEPTH 1/4"
BOLT CLEARANCE DEPTH 39/64"
OVERALL LENGTH 1-3/32"
WEIGHT 0.04 lbs
DRIVE SIZE 3/8"
POINT SIZE 6
FINISH Full Polish
LENGTH TYPE Standard
UNIT OF MEASURE Metric
SPECIFICATION ASME ASME B107.110-2012
SPECIFICATION AS SAE AS4984A
