Proto  |  SKU: J5224H  |  Barcode: 662679161699

Proto J5224H 3/8" Drive Socket 3/4" - 6 Point

$8.31 $11.42

Description

Proto J5224H Includes

  • (1) 3/8" DRIVE SOCKET 3/4" - 6 POINT

Proto J5224H Features

  • Proto® 6 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Proto J5224H Specifications

SIZE 3/4"
NUT END OUTSIDE DIAMETER 1-1/64"
DRIVE END OUTSIDE DIAMETER 1-1/64"
NUT DEPTH 39/64"
BOLT CLEARANCE DEPTH 3/4"
OVERALL LENGTH 1-3/16"
WEIGHT 0.15 lbs
DRIVE SIZE 3/8"
POINT SIZE 6
FINISH Full Polish
LENGTH TYPE Standard
UNIT OF MEASURE Fractional
SPECIFICATION ASME ASME B107.110-2012
SPECIFICATION AS SAE AS4984A
