Proto  |  SKU: J5410M  |  Barcode: 662679180393

Proto J5410M 1/2" Drive Socket 10 mm - 12 Point

$10.00 $13.63

Description

Proto J5410M Includes

  • (1) 1/2" DRIVE SOCKET 10 MM - 12 POINT

Proto J5410M Features

  • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Proto J5410M Specifications

SIZE 10 mm
NUT END OUTSIDE DIAMETER 39/64"
DRIVE END OUTSIDE DIAMETER 55/64"
NUT DEPTH 23/64"
BOLT CLEARANCE DEPTH 55/64"
OVERALL LENGTH 1-31/64"
WEIGHT 0.11 lbs
DRIVE SIZE 1/2"
POINT SIZE 12
FINISH Full Polish
LENGTH TYPE Standard
UNIT OF MEASURE Metric
SPECIFICATION ASME ASME B107.110-2012
SPECIFICATION AS SAE AS4984A
