Proto  |  SKU: J5446  |  Barcode: 662679181321

Proto J5446 1/2" Drive Socket 1-7/16" - 12 Point

$25.29 $43.01

Description

Proto J5446 Includes

  • (1) 1/2" DRIVE SOCKET 1-7/16" - 12 POINT

Proto J5446 Features

  • Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
  • The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
  • The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
  • The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.

Proto J5446 Specifications

SIZE 1-7/16"
NUT END OUTSIDE DIAMETER 1-59/64"
DRIVE END OUTSIDE DIAMETER 1-5/8"
NUT DEPTH 27/32"
BOLT CLEARANCE DEPTH 1-19/64"
OVERALL LENGTH 2-1/8"
WEIGHT 0.98 lbs
DRIVE SIZE 1/2"
POINT SIZE 12
FINISH Full Polish
LENGTH TYPE Standard
UNIT OF MEASURE Fractional
SPECIFICATION ASME ASME B107.110-2012
SPECIFICATION AS SAE AS4984A
