Proto | SKU:
J5778
Proto J5778 1" Drive Socket 2-7/16" - 12 Point
$103.92
$188.39
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 1" DRIVE SOCKET 2-7/16" - 12 POINT
FEATURES:
• Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 2-7/16"
• NUT END OUTSIDE DIAMETER: 3-17/64"
• DRIVE END OUTSIDE DIAMETER: 2-13/32"
• NUT DEPTH: 1-11/16"
• BOLT CLEARANCE DEPTH: 2-11/32"
• OVERALL LENGTH: 3-13/32"
• WEIGHT: 3.20 lbs
• DRIVE SIZE: 1"
• POINT SIZE: 12
• FINISH: Satin
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
• (1) 1" DRIVE SOCKET 2-7/16" - 12 POINT
FEATURES:
• Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 2-7/16"
• NUT END OUTSIDE DIAMETER: 3-17/64"
• DRIVE END OUTSIDE DIAMETER: 2-13/32"
• NUT DEPTH: 1-11/16"
• BOLT CLEARANCE DEPTH: 2-11/32"
• OVERALL LENGTH: 3-13/32"
• WEIGHT: 3.20 lbs
• DRIVE SIZE: 1"
• POINT SIZE: 12
• FINISH: Satin
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
