Proto | SKU:
J5812
Proto J5812 1" Drive Socket 3-1/2" - 12 Point
Free Shipping
$214.76
$432.30
Unit price
/
Unavailable
Description
Description
INCLUDES:
• (1) 1" DRIVE SOCKET 3-1/2" - 12 POINT
FEATURES:
• Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 3-1/2"
• NUT END OUTSIDE DIAMETER: 4-11/16"
• DRIVE END OUTSIDE DIAMETER: 3-5/32"
• NUT DEPTH: 2-1/4"
• BOLT CLEARANCE DEPTH: 3-1/8"
• OVERALL LENGTH: 5-1/8"
• WEIGHT: 9.11 lbs
• DRIVE SIZE: 1"
• POINT SIZE: 12
• FINISH: Satin
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
• (1) 1" DRIVE SOCKET 3-1/2" - 12 POINT
FEATURES:
• Proto® 12 Point Sockets are ideal for use on stubborn or damaged fasteners, and also on fasteners made from soft materials.
• The TorquePlus™ design is a high performance drive configuration which allows for quick and easy socket engagement to the fastener flats, not the corners.
• The TorquePlus™ configuration employs a radius-corner design, shifting contact area and stress away from the fastener corners and distributing contact stresses over a large area of the socket, minimizing slippage.
• The TorquePlus™ internal design minimizes fastener rounding, helps to extend fastener life, and allows the user to more easily turn worn, rounded, or rusted fasteners.
SPECIFICATIONS:
• SIZE: 3-1/2"
• NUT END OUTSIDE DIAMETER: 4-11/16"
• DRIVE END OUTSIDE DIAMETER: 3-5/32"
• NUT DEPTH: 2-1/4"
• BOLT CLEARANCE DEPTH: 3-1/8"
• OVERALL LENGTH: 5-1/8"
• WEIGHT: 9.11 lbs
• DRIVE SIZE: 1"
• POINT SIZE: 12
• FINISH: Satin
• LENGTH TYPE: Standard
• UNIT OF MEASURE: Fractional
• SPECIFICATION ASME: ASME B107.110-2012
