Reed 04705 PES4METRIC with Stops F/SDR 17 & 17.6

INCLUDES:
• (1) PES4METRIC with Stops F/SDR 17 & 17.6

FEATURES:
• Aluminum castings withstand different climate and soil conditions.
• Increased leverage for squeezing due to sliding bar handle.
• Aluminum parts reduce tool weight for easier handling.
• Positive stops prevent damage caused by over-clamping.
• Easy to use in-line because of attached swing bar and no loose parts.

SPECIFICATIONS:
• Actual O.D. 75 - 110 mm
• Number of Stops: 6
• Stop [1]: 98121
• Length: 20" (508 mm)
• Weight: 38.6 lbs (17.5 kg)


Reed offers the best designed tools for stopping flow in ½" up to 8" PE pipe. Different models handle a wide range of pipe sizes and applications. Sliding bar handles make work in tight places easier and increase leverage for tightening. Fine-pitched thread on feed screw allows for a controlled, low-effort squeeze. Grease fittings at friction points make operation smoother and extend tool life. Aluminum bars are anodized or painted for protection from the elements. All PE squeeze-off tools use positive stops to prevent damage caused by over-clamping. Multiple size/SDR settings on one pair of stops provide quick, convenient over-squeeze protection for standard pipe sizes.

NOTE: Reed strongly recommends use of the PEGR Grounding Accessory (#04619) with PE Squeeze-Off Tools. Use a grounding accessory as a precaution against static build-up. Dissipate the charge and minimize the possibility of ignition.
