At a Glance
Anchor Type
Wedge
Weight Capacity
420 lb
Mounting Type
Temporary
Fastener Length
6-1/4 in
Bolt Diameter
1 in
Anchor Diameter
1 in
Material
Galvanized Steel
Sold As
Individual
For Use On
Concrete
Mount Type
Eye
Safety Rating
OSHA 1926.502, OSHA 1910.66, ANSI Z359.1, ANSI Z359.7
Description
Description
SafeWaze FS-EX213 Includes
- (1) Anchor Swivel Hybrid
SafeWaze FS-EX213 Features
- The lightest and nimblest of its kind
- Reusable clamp incorporates a variety of unique components including our swivel D-ring technology
- Incredible strength
- Superior performance
- Weight capacity ANSI 310 lbs./OSHA 420 lbs.
- Range 4" to 10"
- Length 16" / Depth 5.75" / Height 6.50"
- Easy installation and removal for repeated use
- Can be used in horizontal, vertical and overhead applications
- Single user
SafeWaze FS-EX213 Specifications
| Length | 6.25" |
| Diameter | 1" |
| Materials | Return Wire - Aircraft Cable; Cone, Spoons - Stainless Steel; Retaining Bushing, Bolt, Sleeve, Swivel - Zinc Plated Steel; Compression Bushing - Polyethylene |
| Weight Capacity/Max Working Load | ANSI 310 lbs (140.61 kg) - Single User OSHA 420 lbs (191 kg) - Single User |
| Minimum Breaking Load | 10000 lbs - 44 kN |
| Applicable Standards | Meets OSHA 1926-502, OSHA 1910.66, ANSI Z359.1, ANSI Z359.7 |
Toolup Part # :
402857
