SharkBite U782LF Description
The SharkBite U782LF is a 1/2 in. CTS push-to-connect dual tee stop valve adapter designed for fast, reliable connections on PEX, copper, CPVC, PE-RT, and HDPE pipe. Its low-lead DZR brass body installs without soldering or special tools, works on wet or dry lines, and can be rotated or removed after installation for added convenience.
SharkBite U782LF Includes
- (1) 1/2 in. CTS x 1/2 in. CTS x 1/2 in. Push-to-Connect Dual Tee Stop Valve Adapter
SharkBite U782LF Features
- Push-to-connect design for fast installation
- Fits 1/2 in. CTS x 1/2 in. CTS x 1/2 in. CTS connections
- Connects PEX, copper, CPVC, PE-RT, and HDPE pipe in any combination
- No soldering, clamps, unions, glue, or special tools required
- Suitable for hot or cold water lines
- Works on wet or dry lines and can be pressure tested immediately
- Rotatable after installation for easier alignment
- Removable and reusable with a disconnect tool
- Low-lead DZR corrosion-resistant brass body
- Rated to 200 degrees F and 200 PSI
- Ideal for installation in tight spaces
- Approved for underground and behind-the-wall applications when properly wrapped for burial
SharkBite U782LF Specifications
| Fitting Type | Dual tee stop valve adapter |
| Connection Type | Push-to-connect |
| Material | Low-lead DZR brass |
| End 1 Diameter | 1/2 in. CTS |
| End 2 Diameter | 1/2 in. CTS |
| End 3 Diameter | 1/2 in. CTS |
| Maximum Working Temperature | 200 F |
| Minimum Working Temperature | 33 F |
| Maximum Working Pressure | 200 PSI |
| Compatible Pipe Materials | PEX, copper, CPVC, PE-RT, HDPE |
| Removable | Yes |
| For Use with Copper | Yes |
| For Use with CPVC | Yes |
| For Use with PEX | Yes |
| Safety Listing | IAPMO |
| Code Approvals | ASSE 1061, NSF/ANSI 61, NSF/ANSI 372, ASTM E84 |
| Warranty | 25-year limited |
| Product Length (in) | 3.55 |
| Product Width (in) | 1.10 |
| Product Height (in) | 3.55 |
| Product Weight (lb) | 0.21 |
Toolup Part # :
884684
