SharkBite UA24677 Description
The SharkBite UA24677 1-1/2 in. PEX-A Expansion Ring with Stop is designed to connect PEX-A pipe to brass and poly expansion fittings. Its chamfered, injection-molded PEX construction and interior cross hatch help provide easy insertion and secure ring positioning during installation.
SharkBite UA24677 Includes
- (1) 1-1/2 in. PEX-A Expansion Ring with Stop
SharkBite UA24677 Features
- Designed to connect PEX-A pipe to brass and poly expansion fittings
- Chamfered design allows easy insertion
- Stop helps accurately position the ring on the pipe during installation
- Injection-molded PEX ring construction
- Interior cross hatch helps prevent the ring from sliding off the pipe
- Rated for 33 DegreeF at 160 psi minimum and 200 DegreeF at 80 psi maximum
SharkBite UA24677 Specifications
| Size | 1-1/2 in. |
| Product Type | PEX-A Expansion Ring with Stop |
| Material | Injection-molded PEX |
| Pipe Compatibility | PEX-A |
| Application | Connects PEX-A pipe to brass and poly expansion fittings |
| Minimum Working Temperature/Pressure | 33 DegreeF @ 160 psi |
| Maximum Working Temperature/Pressure | 200 DegreeF @ 80 psi |
| Product Length (in) | 1.66 |
| Product Width (in) | 1.93 |
| Product Height (in) | 1.93 |
| Product Weight (lb) | 0.04 |
