SharkBite UC08414135 Description
The SharkBite brass barb reducing tee is a lead-free DZR brass fitting designed to connect 1-1/2 in. and 1-1/4 in. PEX tubing in potable water and hydronic heating systems. Its crimp-style barb ends provide an easy, cost-effective installation and compatibility with PEX-A, PEX-B, and PEX-C pipe.
SharkBite UC08414135 Includes
- (1) Brass Barb Reducing Tee
SharkBite UC08414135 Features
- Lead-free DZR brass construction
- Reducing tee design with 1-1/2 in. x 1-1/2 in. x 1-1/4 in. barb ends
- Crimp-style connection for use with PEX tubing
- Compatible with PEX-A, PEX-B, and PEX-C pipe
- Suitable for potable water distribution and hydronic heating applications
- Maximum working pressure of 160 PSI
- Operating temperature range from 33 F to 200 F
- Meets ASTM F1807, NSF 372, and NSF/ANSI 61 standards
SharkBite UC08414135 Specifications
| Material | Lead-free DZR brass |
| Type | Tee |
| Sub Type | Reducing tee |
| End 1 Diameter | 1-1/2 in. |
| End 2 Diameter | 1-1/2 in. |
| End 3 Diameter | 1-1/4 in. |
| Connection Type End 1 | Crimp |
| Connection Type End 2 | Crimp |
| Connection Type End 3 | Crimp |
| PEX Compatibility | PEX-A/PEX-B/PEX-C |
| Application | Potable water and hydronic heating |
| Maximum Working Pressure | 160 PSI |
| Minimum Working Temperature | 33 F |
| Maximum Working Temperature | 200 F |
| Federal Lead Compliant | Yes |
| Safety Listing | NSF safety listing |
| Code Approvals | ASTM F1807, NSF 372, NSF/ANSI 61 |
| Warranty | 25-year limited |
| Product Weight | 0.52 lb |
