SharkBite UR020A Description
The SharkBite Max 1 in. x 1 in. coupling fitting provides a fast push-to-connect connection for joining PEX, copper, CPVC, PE-RT, or HDPE pipe in potable water applications. Its brass body and stainless steel collet retainer deliver strength, removability, and immediate pressure testing without soldering, clamps, unions, or glue.
SharkBite UR020A Includes
- (1) 1 in. x 1 in. Max Push-to-Connect Brass Coupling Fitting
SharkBite UR020A Features
- Push-to-connect installation for fast connections
- Compatible with PEX, copper, CPVC, PE-RT, and HDPE pipe
- No soldering, clamps, unions, or glue required
- Newly designed stainless steel collet retainer for added strength
- Half the insertion force with double the burst pressure
- Can be installed on wet lines and pressure tested immediately
- Rotatable after installation and removable
- PEX tube liner not required
- Approved for underground and behind-the-wall applications with proper underground wrapping
- Rated to 200 F and 400 psi
- Low-lead DZR corrosion-resistant brass body
- Code approved and IAPMO listed
SharkBite UR020A Specifications
| Series | Max |
| Fitting Type | Coupling |
| Fitting Size | 1 in. x 1 in. |
| Connection | PTC x PTC |
| Connection Type | Push Fit |
| Compatible Pipe Materials | PEX, copper, CPVC, PE-RT, HDPE |
| Material | Brass |
| Application | Potable Water |
| Maximum Working Temperature | 200 F |
| Maximum Working Pressure | 400 psi |
| Removable | Yes |
| Product Length | 3.12 in. |
| Pack Size | 1 |
Toolup Part # :
884220
