Simpson Anchors | SKU:
BP 1/2-3
Simpson Strong-Tie BP 1/2-3 (3" x 3") Bearing Plate with 1/2" Bolt Diameter
$2.40
$3.44
Unit price
/
Unavailable
NOTE: This item is ineligible for free shipping
Description
Description
Simpson BP 1/2-3 Description
The Simpson BP 1/2-3 Bearing Plate is designed for structural connections, providing reliable reinforcement and stability.
Simpson BP 1/2-3 Includes
- (1) Bearing Plate with 1/2" Bolt Diameter
Simpson BP 1/2-3 Features
- Heavy-duty construction for superior strength
- Slotted hole for adjustability
- Hot-dip galvanized finish for corrosion resistance
- Compact size for versatile applications
Simpson BP 1/2-3 Applications
- Wood-to-concrete connections
- Masonry structural reinforcement
- Heavy-duty framing projects
Simpson BP 1/2-3 Installation Overview
- Position edge of plate washer within 1/2" of sheathed edge of sill plate.
- Tighten BPS to each anchor bolt with nut and standard cut-washer.
- Ensure proper alignment and secure fastening.
Simpson BP 1/2-3 Specifications
| Material | 3 Gauge Steel |
| Finish | Hot-Dip Galvanized |
| Bolt Diameter | 1/2" |
| Width | 3" |
| Length | 3" |
NOTE: Standard cut-washer required with BPS 1/2-3 per the 2012/2015/2018/2021 IRC and 2015/2021 SDPWS.
