Simpson Anchors | SKU:
BPS 1/2-6
Simpson Strong-Tie BPS 1/2-6 (3" x 4-1/2") Slotted Bearing Plate with 1/2" Bolt Dia.
$6.21
Unit price
/
Unavailable
Description
Description
Simpson Strong-Tie BPS 1/2-6 Description
The BPS 1/2-6 Slotted Bearing Plate is designed for wood-to-concrete fastening, featuring a slotted hole for adjustability and compatibility with Titen HD heavy-duty screw anchors.
Simpson Strong-Tie BPS 1/2-6 Includes
- (1) BPS 1/2-6 Slotted Bearing Plate
Simpson Strong-Tie BPS 1/2-6 Features
- Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
- Slotted hole allows for adjustability
- Available with a hot-dip galvanized (HDG) finish for higher corrosion resistance
Simpson Strong-Tie BPS 1/2-6 Applications
- Wood-to-concrete fastening
- Masonry anchoring
Simpson Strong-Tie BPS 1/2-6 Installation Overview
- Position the edge of the plate washer within 1/2" of the sheathed edge of the sill plate for shearwall applications.
- Tighten the BPS to each anchor bolt with a nut and standard cut-washer.
- Follow the installation guide for detailed instructions.
Simpson Strong-Tie BPS 1/2-6 Specifications
| Material | 3 ga. |
| Finish | None or HDG |
| Bolt Diameter | 1/2 in. |
| Gauge | 3 |
| Thickness | 0.229 in. |
| Width | 3 in. |
| Length | 4 1/2 in. |
NOTE: Standard cut-washer required with BPS slotted bearing plates. Washer not required when used with Titen HD heavy-duty screw anchors.
