Simpson Anchors | SKU:
BPS 1/2-6HDG
Simpson Strong-Tie BPS 1/2-6HDG (3 in. x 4-1/2 in.) HDG Slotted Bearing Plate with 1/2" Bolt Dia.
$11.16
Unit price
/
Unavailable
Description
Description
Simpson Strong-Tie BPS 1/2-6HDG Description
The HDG Slotted Bearing Plate with 1/2" Bolt Dia. is designed for wood-to-concrete or masonry fastening applications, offering adjustability and corrosion resistance.
Simpson Strong-Tie BPS 1/2-6HDG Includes
- (1) HDG Slotted Bearing Plate with 1/2" Bolt Dia.
Simpson Strong-Tie BPS 1/2-6HDG Features
- Eliminates the need for standard-cut washers when used with Titen HD heavy-duty screw anchors
- Slotted hole allows for adjustability
- Hot-dip galvanized finish for higher corrosion resistance
Simpson Strong-Tie BPS 1/2-6HDG Applications
- Wood-to-concrete fastening
- Masonry fastening
Simpson Strong-Tie BPS 1/2-6HDG Installation Overview
- Position edge of plate washer within 1/2" of sheathed edge of sill plate for shearwall applications
- Use standard cut-washer with BPS slotted bearing plates unless used with Titen HD heavy-duty screw anchors
- Tighten BPS to each anchor bolt with nut and standard cut-washer
Simpson Strong-Tie BPS 1/2-6HDG Specifications
| Material | 3 ga. |
| Finish | Hot-Dip Galvanized |
| Bolt Diameter | 1/2" |
| Thickness | 0.229" |
| Width | 3" |
| Length | 4 1/2" |
NOTE: Standard cut-washer required with BPS 1/2-3, BPS 5/8-3, BPS 3/4-3, BPS 1/2-6, BPS 5/8-6, and BPS 3/4-6 (not provided) per the 2012/2015/2018/2021 IRC and 2015/2021 SDPWS.
