Simpson Anchors | SKU:
BPS 3/4-3HDG
Simpson Strong-Tie BPS 3/4-3HDG (3 in. x 3 in.) Bearing Plate with Slotted Hole for 3/4" Bolt Dia.
$4.32
Unit price
/
Unavailable
Description
Description
Simpson Strong-Tie BPS 3/4-3HDG Description
The Simpson Strong-Tie BPS 3/4-3HDG Bearing Plate is designed for reinforcing and stabilizing structural connections in wood and steel construction projects. It features a slotted hole for adjustability and a hot-dip galvanized finish for corrosion resistance.
Simpson Strong-Tie BPS 3/4-3HDG Includes
- (1) Bearing Plate
Simpson Strong-Tie BPS 3/4-3HDG Features
- Heavy-duty construction from 3 Gauge steel
- Hot-dip galvanized coating for corrosion resistance
- Slotted hole for adjustability
- Compact 3" x 3" size for versatile applications
Simpson Strong-Tie BPS 3/4-3HDG Applications
- Reinforcing structural connections in wood and steel construction
- Heavy-duty framing projects
- Critical structural connections in commercial buildings and bridges
Simpson Strong-Tie BPS 3/4-3HDG Installation Overview
- Position the plate washer within 1/2" of the sheathed edge of the sill plate for shearwall applications.
- Tighten the plate to each anchor bolt with a nut and standard cut-washer.
- Ensure proper alignment and secure fastening.
Simpson Strong-Tie BPS 3/4-3HDG Specifications
| Material | 3 Gauge Steel |
| Finish | Hot-Dip Galvanized |
| Dimensions | 3" x 3" |
| Bolt Diameter | 3/4" |
| Weight | 0.6 lb |
NOTE: Standard cut-washer required with BPS slotted bearing plates. Washer not required when used with Titen HD heavy-duty screw anchors.
