Simpson Anchors | SKU:
CPS12
Simpson Strong-Tie CPS12 Composite Plastic Standoff for 12x12
$35.51
Unit price
/
Unavailable
Description
Description
Simpson Strong-Tie CPS12 Description
The CPS12 Composite Plastic Standoff provides a code-required 1" standoff for wood-to-concrete or masonry applications, featuring a durable composite plastic construction and a black finish for a custom look.
Simpson Strong-Tie CPS12 Includes
- (1) Composite Plastic Standoff
Simpson Strong-Tie CPS12 Features
- Provides code-required 1" standoff
- Multiple sizes to support a variety of projects
- Black finish for a custom look
Simpson Strong-Tie CPS12 Applications
- Fastening wood-to-concrete or masonry
- Indoor architectural projects requiring standoff bases
Simpson Strong-Tie CPS12 Installation Overview
- Drill a 3/4"-diameter hole, 10" into the center of the post.
- Clean out sawdust and fill hole halfway with Simpson Strong-Tie SET-3G epoxy anchoring adhesive.
- Insert all-thread rod while twisting the rod, and allow the epoxy to set and cure.
- Secure standoff to post using four 0.148" x 3" nails.
- Drill a 3/4"-diameter hole per anchor design.
- Clean out dust and fill hole halfway with Simpson Strong-Tie SET-3G, ET-3G or AT-3G anchoring adhesive.
- Insert post subassembly into hole, and allow the epoxy to set and cure.
Simpson Strong-Tie CPS12 Specifications
| Nominal Post Size | 12x12 |
| Width (W) | 11 in. |
| Length (L) | 11 in. |
| Height (H) | 1 in. |
| Material | Composite Plastic |
| Packaging Quantity | 1 |
NOTE: Post bases do not provide adequate resistance to prevent members from rotating about the base and therefore are not recommended for non-top-supported installations (such as fences or unbraced carports).
