Simpson Anchors | SKU:
ECCQ98SDS2.5
Simpson Strong-Tie ECCQ98SDS2.5 (8-3/4" Beam, 8x Post) Quick Install End Column Cap with SDS Screws
Free Shipping
$205.01
Unit price
/
Unavailable
Description
Description
Simpson Strong-Tie ECCQ98SDS2.5 Description
The Simpson ECCQ98SDS2.5 End Column Cap with SDS Screws enhances the strength and stability of your construction projects, providing reliable column-to-beam connections for wood construction.
Simpson Strong-Tie ECCQ98SDS2.5 Includes
- (1) End Column Cap
- (1) Set of SDS Screws
Simpson Strong-Tie ECCQ98SDS2.5 Features
- Provides strong end-of-beam connection for column-to-beams
- Extended area of the column seat offers additional surface area of bearing to distribute the load
- Made from Steel for durability
- Finished with Gray Paint coating
- Certified welds for strength and loading
- Increased uplift loads for earthquake or wind loading
- Features diamond holes for temporary fastening during installation
- Bolt spacing meets NDS code requirements
Simpson Strong-Tie ECCQ98SDS2.5 Applications
- Column-to-beam connections in wood construction
- End-of-beam applications requiring enhanced support
- Projects requiring increased uplift loads for earthquake or wind resistance
Simpson Strong-Tie ECCQ98SDS2.5 Installation Overview
- Align the column cap with the beam and post
- Secure temporarily using diamond holes
- Fasten using the included SDS screws
- Ensure bolt spacing meets NDS code requirements
- Verify the connection for stability
Simpson Strong-Tie ECCQ98SDS2.5 Specifications
| Finish | Gray Paint |
| Material | Steel |
| Beam size | 8-3/4x |
| Fasteners required | All Fasteners Included |
| For Treated Lumber | No |
| Post size | 8x |
| Thickness | 3 Gauge |
