Simpson Anchors | SKU:
SDWS22600DB-R12
Simpson Strong-Tie SDWS22600DB-R12 Strong-Drive (0.220" x 6") T40 SDWS Timber Screw (Exterior Grade) Tan (12 Pack)
$16.86
Unit price
/
Unavailable
Description
Description
Simpson SDWS22600DB-R12 Description
The Simpson SDWS Timber Screw features a double barrier coating for corrosion resistance and a SawTooth point for fast starts without predrilling.
Simpson SDWS22600DB-R12 Includes
- (12) Timber Screw with Double Barrier Coating, 6 in. Length
Simpson SDWS22600DB-R12 Features
- Bold thread design provides superior holding power
- SawTooth point ensures fast starts and reduces installation torque
- Underhead nibs allow for flush driving with reduced splintering
- Large washer head provides a large bearing area
- Size identification on all SDWS screw heads
- 6-lobe T40 drive for positive engagement and improved bit life
- Double-barrier coating for corrosion resistance equivalent to hot-dip galvanization
Simpson SDWS22600DB-R12 Applications
- Structural wood-to-wood connections including ledgers
- Mass timber connections such as CLT wall-to-wall and floor-to-floor
- Surface splines and lap joints
Simpson SDWS22600DB-R12 Specifications
| Diameter | 0.220" |
| Finish | Double Barrier Coating |
| Length | 6" |
| Material | Carbon Steel |
| Color | Tan |
| Drive type | T40 Star Drive |
| Head type | Washer Head |
| Point type | Sawtooth Point |
| Quantity | 12 |
NOTE: The correct fasteners installed in the correct position must be used to achieve published load values
