Simpson Strong-Tie SSWAB1X36HSHDG Description
The Simpson Strong-Tie SSWAB1X36HSHDG is a high-strength anchor bolt designed for steel shearwalls, offering reliable performance and easy installation.
Simpson Strong-Tie SSWAB1X36HSHDG Includes
- (1) High-Strength Anchor Bolt
Simpson Strong-Tie SSWAB1X36HSHDG Features
- Fixed-in-place compression nut to improve performance
- Head stamp for easy identification and inspection
- Supplied with extra nut for attachment to anchor template
Simpson Strong-Tie SSWAB1X36HSHDG Applications
- Anchorage solutions for steel shearwalls
- Foundation reinforcement in construction projects
- Structural anchoring in seismic and wind applications
Simpson Strong-Tie SSWAB1X36HSHDG Installation Overview
- Install SSWAB before the concrete is poured using the appropriate SSWT anchor template and supplied nut; locate per designer
- Install shear reinforcement per the registered design professional before concrete is poured
- Foundation design by designer
Simpson Strong-Tie SSWAB1X36HSHDG Specifications
| Material | ASTM F1554 Grade 36; high-strength (HS) ASTM A449 |
| Finish | None or HDG |
| Application | Anchorage Solutions |
| API Approval | Approved - Full |
NOTE: Ensure the correct fasteners are installed in the correct position to achieve published load values.
Toolup Part # :
819697
