Simpson Anchors | SKU:
THD37600HMG
Simpson Strong-Tie THD37600HMG Titen HD (3/8" x 6") Mechanically Galvanized Heavy-Duty Screw Anchor (50 Pack)
$178.36
$192.27
Unit price
/
Unavailable
Description
Description
Simpson THD37600HMG Description
The Titen HD Screw Anchor Mechanically Galvanized is a high-strength anchor designed for quick and easy installation in concrete and masonry. It features a patented thread design for efficient load transfer and serrated cutting teeth for reduced installation torque.
Simpson THD37600HMG Includes
- (50) 3/8" x 6" Titen HD Screw Anchor Mechanically Galvanized
Simpson THD37600HMG Features
- Head-stamped for easy identification
- Serrated teeth on the tip facilitate cutting and reduce installation torque
- Thread design undercuts to efficiently transfer the load to the base material
- Standard fractional sizes, hole size equals anchor size
- Specialized heat-treating process creates tip hardness for better cutting without compromising ductility
- Hex washer head requires no separate washer, unless required by code
- Fully and easily removable
- Code listed for exterior applications
Simpson THD37600HMG Applications
- Sill plates: Securely fastens sill plates to concrete or masonry
- Ledgers: Provides reliable anchorage for ledger boards
- Post bases: Ensures stable attachment of post bases
- Seating: Suitable for seating applications
- Holdown applications: Ideal for various holdown scenarios
Simpson THD37600HMG Installation Overview
- Drill a hole in the base material using a carbide drill bit matching the anchor's nominal diameter.
- Insert the anchor through the fixture and into the hole.
- Tighten the anchor until the hex-washer head contacts the fixture.
Simpson THD37600HMG Specifications
| Material | Carbon steel |
| Finish | Mechanically galvanized |
| Diameter | 3/8" |
| Length | 6" |
| Drill Bit Diameter | 3/8" |
| Drive Type | 9/16" Hex |
| Fixture Hole Size | 1/2"-9/16" |
| Head Type | Hex Head |
| Quantity | 50 |
NOTE: Use the correct fasteners installed in the correct position to achieve published load values
