Southwire | SKU:
25230001-6
Southwire 25230001-6 In-Line 120V/20 AMP GFCI User Attachable
$87.12
$128.12
Unit price
/
Unavailable
Description
Description
In-Line 120V/20 AMP GFCI User Attachable 25230001-6 Description
The in-line user attachable is ideal for existing equipment without GFCI protection, and can be easily attached by connecting the GFCI in series with the supply cable 9 to 10 inches from the plug end to provide GFCI protection.
In-Line 120V/20 AMP GFCI User Attachable 25230001-6 Features
- Applications Include: Pressure Washers, Drain Snakes, Floor Cleaners, Industrial Appliances, Power Tools, Pumps, Boat Lifts, Extension Cords
- Grounded Neutral: 4 Ohms
- Trip Response Time for Ground Fault and Grounded Neutral Trip: Less Than 25mS and grounded neutral trip
- Radio Frequency Noise Susceptibility: Operates Within Normal Limits With 0.5 Volts Injected On Power Line 150Khz-230Mhz
- Effect of 10 Amp Turn DC Shock Fault Trip: 5% Maximum Trip Level Variation on Ground
- Endurance: 3,000 Operations Minimum
- Overload Current: Six Times Rated Current
- Insulation Voltage: 1500 Vrms - 1 Min.
- Cord Gauge: Accepts 18 - 12 AWG (SJT)
- Power On Indication: Lighted Indicator
In-Line 120V/20 AMP GFCI User Attachable 25230001-6 Specifications
