Southwire HB9AX48 Description
The Southwire HB9AX48 open-top box roller assembly combines an open-top box roller with a 48 inch crossbar and two tray clamps to guide cable smoothly along straight runs or across outside vertical risers. It features a high-strength, lightweight, one-piece die cast aluminum frame and flexible mounting above or inside cable tray.
Southwire HB9AX48 Includes
- (1) Open-Top Box Roller Assembly (HB9AX48)
- (1) HB1A9 Open-Top Box Roller
- (1) 48 in Crossbar
- (2) HBFB Tray Clamps
Southwire HB9AX48 Features
- Combines the HB1A9 Open-Top Box Roller with a 48 inch crossbar and two HBFB tray clamps
- Guides cable smoothly along straight runs or across outside vertical risers
- High-strength, lightweight, one-piece die cast aluminum frame
- Flexible mounting above or inside cable tray using standard HB3AX48 crossbar
- Crossbar design adds stiffness to the tray compared to rung-mounted rollers
- 4.8 in cable space between rollers
Southwire HB9AX48 Specifications
| Model Number | HB9AX48 |
| Frame Material | Die cast aluminum |
| Crossbar Length | 48 in |
| Cable Space Between Rollers | 4.8 in |
| Product Weight | 7.8 lbs |
| Shipping Weight | 22.1 lbs |
| Product Length | 6.85 in |
| Product Width | 48 in |
| Product Height | 13.94 in |
Toolup Part # :
869264
