Tiger TR7CB-0200-15 Description
The Tiger TR7 Series hand chain hoist is a compact industrial chain block designed for reliable manual lifting. This 2 ton model with a 15 foot lift features rugged steel construction, low headroom for tight installations, certified light load protection, and proof-tested performance for demanding jobsite and industrial applications.
Tiger TR7CB-0200-15 Includes
- (1) TR7 Series Hand Chain Hoist
Tiger TR7CB-0200-15 Features
- 2 ton capacity with 15 foot lift
- Rugged steel body construction is lightweight, compact, and impact resistant
- Especially low headroom supports installation in restricted environments
- Certified 2% light load protection
- Double cover protection for the brake chamber
- Drop forged and heat treated alloy hooks
- High quality calibrated alloy load chain
- Heat treated alloy steel triple spur gears and pinion shaft
- 8 point multi start threaded pinion shaft helps increase brake reaction times
- Proof tested to 1.5 times rated capacity
- Meets or exceeds BS EN 13157: 2004+A1:2009, ANSI/ASME B30.16, AS 1418.2, and SANS 1594
- Operating temperature range from -40 DegreeC to +50 DegreeC (-40 DegreeF to +122 DegreeF)
Tiger TR7CB-0200-15 Specifications
| Brand | Tiger |
| Series | TR7 |
| Product Type | Hand Chain Hoist |
| Operation | Manual |
| Capacity | 2 Ton |
| Lift | 15 ft |
| Construction | Steel body |
| Headroom | Low headroom design |
| Light Load Protection | Certified 2% of rated capacity |
| Hook Material | Drop forged heat treated alloy |
| Load Chain | Calibrated alloy load chain |
| Gear Material | Heat treated alloy steel |
| Proof Test | 1.5 times rated capacity |
| Operating Temperature | -40 DegreeC to +50 DegreeC (-40 DegreeF to +122 DegreeF) |
| Standards | BS EN 13157: 2004+A1:2009, ANSI/ASME B30.16, AS 1418.2, SANS 1594 |
