Viega 98315 Description
The Viega MegaPress 316 FKM adapter provides a secure press connection to a female pipe thread transition for stainless steel piping systems. Built from 316 stainless steel with an FKM sealing element, it is designed for use with Schedule 5 to Schedule 40 stainless steel pipe and is intended for installation with MegaPress XL rings and a PressBooster/Z3 actuator.
Viega 98315 Includes
- (1) Viega MegaPress 316 FKM adapter (press x female pipe thread)
- (1) FKM sealing element
- (1) Grip ring
- (1) Separator ring
Viega 98315 Features
- Press connection x female pipe thread (FPT) adapter
- 2-1/2 in press end x 2-1/2 in FPT end
- 316 stainless steel construction
- FKM sealing element
- For use with Schedule 5 to Schedule 40 stainless steel pipe
- Smart Connect Technology
- Must be installed with MegaPress XL rings and PressBooster/Z3 actuator
Viega 98315 Specifications
| System | MegaPress 316 FKM |
| Model | 6812XL |
| Material | 316 stainless steel |
| Connection Type | Press x Female Pipe Thread |
| Press Size | 2-1/2 in |
| Thread Size | 2-1/2 in |
| Thread Type | FPT |
| Seal Material | FKM |
| Pipe Compatibility | Schedule 5 to Schedule 40 stainless steel pipe |
| Country of Origin | DE |
| Each UPC | 691514983158 |
| Product Length (in) | 3.843 |
| Product Width (in) | 3.543 |
| Product Height (in) | 3.543 |
| Product Weight (lb) | 1.84 |
Toolup Part # :
888567
