Werner | SKU:
A330000
Werner A330000 Steel D-Ring Anchorage Connector
$28.00
$52.75
Unit price
/
Unavailable
Description
Description
Werner A330000 Description
Made with alloy and stainless steel, the WernerCo A330000 D-Ring Anchorage Connector is reusable and designed to be attached to metal structures with a minimum thickness of ¼ inch. Quickly install the D-Ring Anchorage Connector with a Grade 5 or stronger ? inch - 11 steel hex head bolt and nut. Meets ANSI Z359.18 and OSHA Standards.
Werner A330000 Includes
- (1) D-ring anchorage connector
Werner A330000 Features
- Made with alloy and stainless steel
- Minimum Breaking Strength (MBS): 5,000 lb
- 2-3/8 inch D-ring
- Fasten with a 5/8 inch - 11 Grade 5 steel hex head bolt and nut
- Meets ANSI Z359.18 and OSHA Standards
Werner A330000 Specifications
| Style | Roofing |
| Certifications / Code | Meets ANSI Z359.18 and OSHA Standards |
| Permanent/Temporary | Temporary |
| Material | Alloy and Stainless Steel |
| Approx. Shipping Weight (lb) | 1 |
| Length | 6 in (154 mm) |
| Width | 3 ? in(80 mm) |
| Connection Size | 2 ? in(61 mm |
| Hole Diameter | ? in(17 mm |
| Minimum Breaking Strength (MBS) | 5,000 lbs(22.2 kN |
